Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-246
Tray 1 Miss Feed Jam/ Option Regi On Jam
After a paper was fed from Tray 1, it did not reach the Registration Sensor.
Applicable Fault Code
• 071-101: Tray 1 Miss Feed Jam
Initial Actions
• Check the condition of the paper in tray.
• Check that the media is supported from tray.
• Check that the Paper Guides are set correctly.
• Check appropriate tray jam clearance door.
• If the problem persists, perform the following procedure.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• Turn Roller Assembly, PL 2.2.1
• Feed Roller Clutch, PL 2.2.8
• Tray 1 Feed Roller Kit, PL 2.2.99
• Registration Sensor, PL 5.1.3
• Bypass Tray Turn Roller, PL 5.1.8
• Turn Roller Clutch, PL 5.1.9
• Paper Handling Motor (P/H Drive Assembly), PL 11.1.19
• MCU PWB, PL 12.1.15
• Paper Jam Sensor, PL 15.2.3
• Feeder PWB, PL 15.2.33
Troubleshooting Procedure
Step Actions and Questions Yes No
1. Check the installation of Tray 1.
Is Tray 1 installed properly?
Go to step 2. Reinstall Tray 1.
2. Check the paper transport path.
Is there any debris found on the paper transport
path?
Remove the debris
from the paper
transport path.
Go to step 3.
3. Check the installation of the Feed Rollers (REP
2.15 Feed Roller/ Retard Roller Assembly on
page 4-54).
Are the Feed Rollers installed properly?
Go to step 4. Reinstall the Feed
Rollers.

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
