Xerox Phaser 7100 Service Manual

General and Operation Overview
Phaser 7100 Service Manual Xerox Internal Use Only1-58
Intermediate Transfer Belt (Transfer/ Cleaning)
• Waste Cartridge Full Sensor (Toner Full Sensor) - Detects whether the Waste Cartridge is full with
waste toner.
• Waste Toner Motor (IBT Cleaner Motor Assembly) - Drives the Paddle for transporting the waste
toner.
s7100-191
Waste Cartridge Full Sensor
Waste Toner Motor
Waste Cartridge
IBT Belt Assembly
CTD Sensor Assembly
Belt Retract Motor
Belt Retract Sensor
Left CTD Sensor
Right CTD Sensor
2nd BTR
(Transfer Roller)
Temperature Sensor
