Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-360
116-710 HP-GL/2 Memory Overflow
HP-GL/2 memory overflows.
Applicable Fault Code
• 116-710: HP-GL Spool File Overflow
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
116-711 PLW Size/ Orientation Mismatch
Form Overlay is impossible because the size/ orientation of the PLW form's drawing is different from
that of the paper.
Applicable Fault Code
• 116-711: <PLW form synthesis error> Form Overlay is impossible because the size/orientation of
the PLW form's drawing is different from that of the paper.
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Troubleshooting Procedure
Step Actions and Questions
1. Increase the HP-GL spool size.
Or, install the HDD.
Troubleshooting Procedure
Step Actions and Questions
1. Select paper that has the same size and orientation as the registered form.

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
