Xerox Phaser 7100 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-357
116-397 AAAmgr Illegal Setting Area Coverage Threshold
When the setting value of the system data in the boot sequence, fulfilled any of the following
conditions. 720-061 (threshold B) <= 720-060 (threshold A)
• If the value of Chain-Link 720-060 is lower than 720-061 a Fault will be detected.
• As a Fault will be detected when the value of Chain-Link 720-060 is lower than 720-061, the value
of Chain-Link 720-060 must not be lower than 720-061.
Applicable Fault Code
• 116-397: Plain Total Color Judgment Threshold Value Settings Incorrect
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Troubleshooting Procedure
Step Actions and Questions
1. Set the value of system data such that it conforms to the following relative value.
Chain-Link 720-061 (threshold B) > Chain-Link 720-060 (threshold A)
Note: The value of Chain-Link 720-060 cannot be lower than that of 720-061.

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
