Xerox Phaser 7100 Service Manual

Plug/Jack and Wiring Diagrams
Phaser 7100 Service Manual Xerox Internal Use Only7-44
Motor On (Drum Motor YMC) The On/ Off Control signal of the Drum Motor (Y/ M/ C)
Motor BRK (Drum Motor YMC) The Control signal of the Drum Motor (Y/ M/ C)
CW/ CCW (Drum Motor YMC) The Forward rotation/ Reverse rotation Control signal of the Drum
Motor (Y/ M/ C)
Motor Gain (Drum Motor YMC) The Control signal of the Drum Motor (Y/ M/ C)
Alarm (Drum Motor K) The Alarm signal from the Drum Motor (K)
Clock (Drum Motor K) The Clock signal of the Drum Motor (K)
Motor On (Drum Motor K) The On/ Off Control signal of the Drum Motor (K)
Motor BRK (Drum Motor K) The Control signal of the Drum Motor (K)
CW/ CCW (Drum Motor K) The Forward rotation/ Reverse rotation Control signal of the Drum
Motor (K)
Motor Gain (Drum Motor K) The Control signal of the Drum Motor (K)
Alarm (Paper Handling Motor) The Alarm signal from the Paper Handling Motor
Clock (Paper Handling Motor) The Clock signal of the Paper Handling Motor
Motor On (Paper Handling Motor) The On/ Off Control signal of the Paper Handling Motor
Motor BRK (Paper Handling Motor) The Control signal of the Paper Handling Motor
CW/ CCW (Paper Handling Motor) The Forward rotation/ Reverse rotation Control signal of the Paper
Handling Motor
Motor Gain (Paper Handling Motor) The Control signal of the Paper Handling Motor
Drive 1 Signal Lines (Continued)
Signal Line Name Description

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
