Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-352
116-389 No Add-On RAM that Should Be
RAM error has occurred. Although the configuration (with HDD, etc.) requires an Extension RAM, it was
detected that the Extension RAM is not installed.
Applicable Fault Code
• 116-389: The necessary additional RAM was not installed.
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• 1 GB SO-DIMM (Extension System Memory), PL 12.4.3
• Image Processor PWB, PL 12.4.1
Troubleshooting Procedure
Step Actions and Questions
1. Reinstall or replace the Extension Memory (REP 12.19 Memory (Optional) on page 4-234).
2. If the problem persists, go to Common System Fail on page 2-406.
