Xerox Phaser 7100 Service Manual

Plug/Jack and Wiring Diagrams
Xerox Internal Use Only Phaser 7100 Service Manual 7-3
Print Engine Plug/Jack Designators
Print Engine Plug/Jack Designators
P/J Map Coordinates Remarks
101 8 G-106 Connection between the Main UI Harness Assembly (PL 12.3.10) and the
Control Panel Harness Assembly (PL 1.1.35).
102 1 E-108 Connection between the Control Panel Harness Assembly (PL 1.1.35) and
the Control Panel (PL 1.1.17).
105 2 C-105 Connection between the Developer Motor PWB (PL 11.1.16) and the
Developer Motor (Y) (PL 11.1.11).
106 2 C-106 Connection between the Developer Motor PWB (PL 11.1.16) and the
Developer Motor (M) (PL 11.1.11).
107 2 C-106 Connection between the Developer Motor PWB (PL 11.1.16) and the
Developer Motor (C) (PL 11.1.11).
108 2 C-107 Connection between the Developer Motor PWB (PL 11.1.16) and the
Developer Motor (K) (PL 11.1.11).
111 2 B-104 Connection between the Developer Motor (Y) (PL 11.1.11) and the
Developer Motor PWB (PL 11.1.16).
112 2 C-105 Connection between the Developer Motor (M) (PL 11.1.11) and the
Developer Motor PWB (PL 11.1.16).
113 2 C-106 Connection between the Developer Motor (C) (PL 11.1.11) and the
Developer Motor PWB (PL 11.1.16).
114 2 D-107 Connection between the Developer Motor (K) (PL 11.1.11) and the
Developer Motor PWB (PL 11.1.16).
144 8 F-105 Connection between the X Pro Harness Assembly (PL 12.3.3) and the
EEPROM PWB (PL 12.1.18).
242 1 D-104 Connection between the Front Harness Assembly (PL 4.2.11) and the
Fuser Drive Assembly (Fuser Unit Motor) (PL 4.2.16).
14 I-111
300 10 F-110 Connection between the Image Processor PWB (PL 12.4.1) and the ESS
Power Harness Assembly (PL 12.3.2).
302 10 F-109 Connection between the Hard Disk Drive (PL 12.4.20) and the Image
Processor PWB (ESS PWB) (PL 12.4.1).
304 10 F-107 Connection between the Image Processor PWB (PL 12.4.1) and the Main
Harness Assembly (PL 12.3.1)
305 10 F-108 Connection between the Image Processor PWB (ESS PWB) (PL 12.4.1)
and the Video Harness Assembly (PL 12.3.7).
306 10 F-108 Connection between the Image Processor PWB (ESS PWB) (PL 12.4.1)
and the Main UI Harness Assembly (PL 12.3.10).

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
