Plug/Jack and Wiring Diagrams
Phaser 7100 Service Manual Xerox Internal Use Only7-4
310 10 F-109 Connection between the Hard Disk Drive (PL 12.4.20) and the Image
Processor PWB (ESS PWB) (PL 12.4.1).
451 8 C-110 Connection between the MCU PWB (PL 12.1.15) and the Main UI Harness
Assembly (PL 12.3.10).
9E-102
452 8 C-110 Connection between the MCU PWB (PL 12.1.15) and the Main Harness
Assembly (PL 12.3.1).
9E-102
453 8 G-112 Connection between the MCU PWB (PL 12.1.15) and the Turn Clutch
Assembly (PL 5.1.9).
454 8 D-110 Connection between the MCU PWB (PL 12.1.15) and the Toner CRUM
Harness Assembly (PL 8.1.18)
9 F-102
455 8 E-110 Connection between the MCU PWB (PL 12.1.15) and the Main Harness
Assembly (PL 12.3.1).
9 G-102
456 8 G-112 Connection between the MCU PWB (PL 12.1.15) and the Main CTD
Harness Assembly (PL 12.3.8).
457 8 G-111 Connection between the MCU PWB (PL 12.1.15) and the Main CTD
Harness Assembly (PL 12.3.8).
458 8 G-112 Connection between the MCU PWB (PL 12.1.15) and the Registration
Clutch Assembly (PL 5.1.11).
459 7 B-103 Connection between the MCU PWB (PL 12.1.15) and the DRW Fuser
Harness Assembly (PL 4.1.7).
8 G-110
460 8 G-111 Connection between the MCU PWB (PL 12.1.15) and the X-Pro Harness
Assembly (PL 12.3.3).
461 8 E-112 Connection between the MCU PWB (PL 12.1.15) and the Option Harness
Assembly (PL 12.3.5).
462 8 F-110 Connection between the MCU PWB (PL 12.1.15) and the Dispense
Harness Assembly (PL 8.1.19).
463 8 G-112 Connection between the MCU PWB (PL 12.1.15) and the Main Harness
Assembly (PL 12.3.1).
9 I-104
464 8 E-112 Connection between the MCU PWB (PL 12.1.15) and the Option Harness
Assembly (PL 12.3.5).
465 8 F-112 Connection between the MCU PWB (PL 12.1.15) and the Main Harness
Assembly (PL 12.3.1).
9 G-104
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks
