Xerox Phaser 7100 Service Manual

Plug/Jack and Wiring Diagrams
Xerox Internal Use Only Phaser 7100 Service Manual 7-5
466 8 F-112 Connection between the MCU PWB (PL 12.1.15) and the Main Harness
Assembly (PL 12.3.1).
9 H-104
467 8 B-110 Connection between the MCU PWB (PL 12.1.15) and the Main Harness
Assembly (PL 12.3.1).
9E-103
468 8 D-112 Connection between the MCU PWB (PL 12.1.15) and the Main Harness
Assembly (PL 12.3.1).
9 F-104
469 8 C-112 Connection between the MCU PWB (PL 12.1.15) and the Main Harness
Assembly (PL 12.3.1).
9E-105
470 8 B-112 Connection between the MCU PWB (PL 12.1.15) and the Main Harness
Assembly (PL12.3.1).
9E-104
471 8 G-112 Connection between the MCU PWB (PL 12.1.15) and the Paper Handling
Motor Harness Assembly (PL 12.3.9).
472 8 B-112 Connection between the MCU PWB (PL 12.1.15) and the Main Harness
Assembly (PL 12.3.1).
9E-104
473 8 G-111 Connection between the MCU PWB (PL 12.1.15) and the Registration
Harness [Registration Chute Assembly] (PL 5.1.1).
474 8 B-111 Connection between the MCU PWB (PL 12.1.15) and the Deve Motor
Harness Assembly (PL 11.1.24).
475 8 F-112 Connection between the MCU PWB (PL 12.1.15) and the Main Harness
Assembly (PL 12.3.1).
9 G-104
476 8 E-110 Connection between the MCU PWB (PL12.1.15) and the Main Harness
Assembly (PL 12.3.1).
9 G-102
477 8 D-112 Connection between the MCU PWB (PL 12.1.15) and the Main Harness
Assembly (PL 12.3.1).
9 F-104
492 8 E-111 Not used.
501 8 C-106 Connection between the AC PWB Assy (PL 12.1.16) and the AC In
Harness Assembly (PL 12.1.14).
502 8 E-106 Connection between the AC PWB Assy (PL 12.1.16) and the AC LV
Harness Assembly (PL 12.3.4).
503 7 D-106 Connection between the AC PWB Assy (PL 12.1.16) and the DWR Fuser
Harness Assembly (PL 4.1.7).
8 G-107
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks
