Plug/Jack and Wiring Diagrams
Phaser 7100 Service Manual Xerox Internal Use Only7-6
505 8 E-107 Connection between the AC PWB Assy (PL 12.1.16) and the Option
Harness Assembly (PL 12.3.5).
521 10 I-108 Connection between the LVPS PWB (PL 12.2.1) and the AC LV Harness
Assembly (PL 12.3.4).
522 4 F-111 Connection between the LVPS PWB (PL 12.2.1) and the Top Harness
Assembly (PL 12.2.24).
10 G-108
523 10 G-106 Connection between the LVPS PWB (PL 12.2.1) and the Main Harness
Assembly (PL 12.3.1).
524 10 G-107 Connection between the LVPS PWB (PL 12.2.1) and the Main Harness
Assembly (PL 12.3.1).
11 E-103
525 10 G-108 Connection between the LVPS PWB (PL 12.2.1) and the Main Harness
Assembly (PL 12.3.1).
11 E-104
526 10 G-109 Connection between the LVPS PWB (PL 12.2.1) and the ESS Power
Harness Assembly (PL 12.3.2).
527 10 G-108 Connection between the LVPS PWB (PL 12.2.1) and the Main Harness
Assembly (PL 12.3.1).
11 E-104
528 10 G-107 Connection between the LVPS PWB (PL 12.2.1) and the Main Harness
Assembly (PL 12.3.1).
11 E-103
529 10 G-107 Connection between the LVPS PWB (PL 12.2.1) and the Main Harness
Assembly (PL 12.3.1).
11 E-103
551 10 G-110 Connection between the Main Harness Assembly (PL 12.3.1) and the HV1
Power Supply PWB (PL 12.2.15)
11 F-106
552 3 E-106 Connection between the Top Harness Assembly (PL 12.2.24) and the
HVPS2 PWB (PL 12.1.2)
5 H-108
601 1 D-103 Connection between the DWR Fuser Harness Assembly (PL 4.1.7) and the
Fuser Assembly (PL 10.1.1)
7 I-109
2711 6 C-110 Connection between the Main Harness Assembly (PL 12.3.1) and the
Front Harness Assembly (PL 4.2.11).
9 B-111
13 C-110
4021 10 F-109 Connection between the ROS Assembly (PL 7.1.1) and interim connector.
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks
To Next Page
