Xerox Phaser 7100 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-233
300K Kit Error
The print volume (PV) of the Dispense Motor, Trickle Motor, or Registration Roller has reached the
specified value (A4 LEF imp = 300 kPV) which indicates that the lifespan is approaching the end.
Applicable Fault Code
• 041-401: 300K Kit Quality Life End (operation can still continue) (quality lifespan has ended)
(ERU)
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure.
Troubleshooting Reference
Applicable Parts
Wiring and Plug/Jack Map
References
• Registration Roller (Registration Chute Assembly), PL 5.1.1
• Developer Housing Assemblies (C/ M/ Y/ K), PL 8.1.5 - PL 8.1.8
• Waste Auger Assembly (Trickle Guide), PL 8.1.10
• Dispense Motor Assembly, 8.1.15
Troubleshooting Procedure
Step Actions and Questions
1. Perform DC135 HFSI on page 2-19.
2. Reset the 300K Kit (Chain-Link 950-876).

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
