Xerox Phaser 7100 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-89
Cont Program ROM Fail-2
Write command failure of Program ROM 1.
Applicable Fault Code
• 016-336: Cont Program ROM Diagnostic Fail-2
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• I/P PWB, PL 12.4.1
• 1 GB DDR2 DIMM, PL 12.4.2
Troubleshooting Procedure
Step Actions and Questions
1. Remove and reinstall the I/P PWB ROM DIMM #1 (REP 12.18 Memory (Standard) on page 4-232).
2. Replace the I/P PWB ROM DIMM #1(REP 12.18 Memory (Standard) on page 4-232).
3. Replace the I/P PWB (REP 12.17 Image Processor (I/P) PWB on page 4-228).
