Xerox Phaser 7100 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-451
Sheet Feeder Troubleshooting
Option Feeder Mode Error
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• Feeder PWB, PL 15.2.33
Troubleshooting Procedure
Step Actions and Questions Yes No
1. Check the Tray where the problem has occurred.
2. Check the firmware version of the Feeder PWB.
Is it the latest Feeder PWB firmware version?
If Feeder PWB firmware version is not available,
replace the Feeder PWB (REP 15.22 Feeder PWB
on page 4-285).
Replace the Feeder
PWB (REP 15.22
Feeder PWB on
page 4-285).
Update the
firmware version
of the Feeder PWB.
