Xerox Phaser 7100

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-203
Bypass Tray Error: Paper Empty
The system detected that the Bypass Tray has no paper.
Applicable Fault Code
• 024-954: Bypass Tray Empty
Initial Actions
• Inspect the tray to ensure that it is free of obstructions and is loaded with supported paper.
• If the problem persists, perform the following procedure.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• Front Harness Assembly, PL 4.2.11
• Bypass Tray No Paper Sensor, PL 4.4.3
• MCU PWB, PL 12.1.5
• Main Harness Assembly, PL 12.3.1
• 550-Sheet Feeder on page 7-64
Troubleshooting Procedure
Step Actions and Questions Yes No
1. Check the Bypass Tray No Paper Sensor
operation.
Perform DC330 Component Control on
page 2-26 [071-100] to check the operation of
the Bypass Tray No Paper Sensor.
Is the Sensor working properly?
Replace the MCU PWB
(REP 12.4 MCU PWB
on page 4-206).
Go to step 2.
2. Check the connection of the Bypass Tray No
Paper Sensor.
Check the connection between the Bypass Tray
No Paper Sensor and MCU PWB.
Are the connectors P/J4752, P/J4751, and P/J475
connected securely?
Go to Step 3 Connect the
connectors P/J4752,
P/J4751, and P/J475.
3. Check the conductivity between the Bypass Tray
No Paper Sensor and Relay Connector.
Is the connection between P/J4752 <=> P/J4751
conducting properly?
Go to step 4. Replace the Front
Harness Assembly.
4. Check the conductivity between the Relay
Connector and MCU PWB.
Is the connection between P/J4751 <=> P/J475
conducting properly?
Go to step 5. Replace the Main
Harness Assembly.
