Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-182
Invalid IOT Paper Size Group Info
The paper size group settings in the Controller does not match with the paper size group information
that is detected by the IOT.
Applicable Fault Code
• 024-361: The paper size group data is different between the ESS and the IOT.
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Troubleshooting Procedure
Step Actions and Questions
1. Go to IOT System Fail on page 2-407.
2. If the problem persists, replace the I/P PWB (REP 12.17 Image Processor (I/P) PWB on page 4-228).
Troubleshooting Procedure
Step Actions and Questions
1. Initialize the NVM (User Area) (DC301 NVM Initialize on page 2-50).
2. Check the paper size group setting in the Controller and set a correct value.
3. Check the Paper Size Switch (Tray 1 Error: Size Unknown on page 2-191, Tray 2, 3, 4 Error: Size
Unknown on page 2-193).

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
