Xerox Phaser 7100 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-183
024-362/ 024-363
A page error has occurred due to one of the following problems.
• During IOT output, the Page Sync becomes active before the output data is written until the FIFO
is Full. Although it is usually resistant to noise interference, extreme noise may also be a cause.
• During IOT output, the Page Sync becomes negated before the specified size is output. Although
it is usually resistant to noise interference, extreme noise may also be a cause.
Applicable Fault Codes
• 024-362: <Image Output> PAGE-SYNC occurred before video output preparation completes.
• 024-363: <Image Output> PAGE-SYNC completion error during video output
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• Image Processor PWB, PL 12.4.1
Troubleshooting Procedure
Step Actions and Questions
1. Go to IOT System Fail on page 2-407.
2. If the problem persists, replace the I/P PWB (REP 12.17 Image Processor (I/P) PWB on page 4-228).
