Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-454
Voltage
The following diagram illustrates the voltage supply for the Phaser 7100 printer.
MCU PWB
AC PWB Fuser Unit
LINE
NUT
Main Switch
FUSER RELAY ON
Heater
Control
SUB HEAT ON
MAIN HEAT ON
LVPS PWB
Front Cover
Interlock
Switch
Waste
Cartridge
Set Switch
Toner Cover
Interlock
Switch
Laser Unit
I/L+5VDC
DC Power Supply
+5VDC
+24VDC
+5VDC
+3.3VDC
+24VDC
RELAY ON
I/L +24VDC
Drum Motor YMC
Drum Motor K
Paper Handling
Motor
Fuser Motor
Developer Motor
PWB
IP PWB
STBY +5VDC
ON/OFF
STBY
+5VDC
+24VDC
I/L+24VDC
I/L+24VDC
+3.3VDC
Feeder PWB
Duplex PWB
Duplex In Clutch
Duplex Motor
Option Feed Drive
Feed Roller Clutch
Turn Roller Clutch
I/L+24VDC
I/L+24VDC
Feed Roller Clutch
Turn Roller Clutch
Registration Clutch
Dispense Motors (Y/M/C/K)
s7100-433
