Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-368
116-745 ART Command ERR
During Decompose, the Decomposer checks for errors in grammar and values that exceed their
respective limit values.
Applicable Fault Code
• 116-745: <ART Command Error> During Decompose, the Decomposer checks for errors in
grammar and values that exceed their respective limit values.
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
116-746 Selected Form Not Registered
The specified form is not registered.
Applicable Fault Code
• 116-746: <Form Overlay Error> The specified form is not registered.
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Troubleshooting Procedure
Step Actions and Questions
1. After checking the registered logos using the Operation Panel utility, delete the unnecessary logos.
Or, delete the unnecessary logos with Print Command.
Troubleshooting Procedure
Step Actions and Questions
1. Increase the size of the Form Registration Area using the Operation Panel.
Or, install the HD.

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
