Xerox Phaser 7100 Service Manual

General and Operation Overview
Phaser 7100 Service Manual Xerox Internal Use Only1-20
Parts of the Printer
Note: For additional tips, refer to the Doors and Covers video (also available in the Phaser 7100
Training materials).
Front View
1. Power Switch 6. Cover A
2. Cover A Release Latch 7. Cover B Release Button
3. Toner Cartridge Cover 8. Bypass Tray
4. Output Tray 9. Tray 1
5. Control Panel 10. Optional 550-Sheet Feeders (Trays 2–4)
Note: A 250-sheet adjustable Tray 1 and a 150-sheet Bypass Tray are standard. Up to three optional
550-Sheet Feeders provide a maximum of five trays, for a maximum 2,050-sheet input capacity.
456
8
9
10
2
1
3
7
s7100-154
