Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-424
Turn Roller Clutch
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• Turn Roller Clutch (Turn Clutch Assembly), PL 5.1.9
• MCU PWB, PL 12.1.15
• Paper Transport on page 7-51
Troubleshooting Procedure
Step Actions and Questions Yes No
1. Check the Turn Roller Clutch operation.
Perform DC330 Component Control on
page 2-26 [071-016] to check the operation of
the Turn Roller Clutch.
Is the Turn Roller Clutch operating properly?
Replace the MCU PWB
(REP 12.4 MCU PWB
on page 4-206).
Go to step 2.
2. Check the connection between the Turn Roller
Clutch and MCU PWB.
Is the connector P/J453 connected securely?
Go to step 3. Connect the connector
P/J453.
3. Check the resistance of the Turn Roller Clutch
Turn Off the power, remove the Turn Roller Clutch
(REP 5.4 Turn Clutch Assembly on page 4-119),
and check the wire resistance between the two
terminals.
Is the resistance 137 Ohms (at 20° C)?
Go to step 4. Replace the Turn
Clutch Assembly (REP
5.4 Turn Clutch
Assembly on
page 4-119).
4. Check the voltage supply (+24VDC) to the Turn
Roller Clutch.
Measure the voltage between the MCU PWB
GND <=> P/J453-1.
Is there a voltage (approx. +24VDC) output?
Close the Interlock Switch and check.
Replace the Turn
Clutch Assembly (REP
5.4 Turn Clutch
Assembly on
page 4-119).
Go to +24VDC Power
Troubleshooting on
page 2-455.

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
