Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-196
(Y/ M/ C) Imaging Unit Cartridge Error: Life End
Imaging Unit error has occurred due to one of the following problems.
• During color printing, it was detected that printing cannot be continued because of (Y/ M/ C)
Imaging Unit Life End.
• Or, color printing was specified when printing cannot be continued because of (Y/ M/ C) Imaging
Unit Life End.
Applicable Fault Codes
• 024-933: Operation Y Imaging Unit End of Life
• 024-940: Operation M Imaging Unit End of Life
• 024-941: Operation C Imaging Unit End of Life
Initial Actions
• Check the Imaging Unit life. Access CWIS > Status > Consumables.
• If the problem persists, perform the following procedure.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• Imaging Unit (Y/ M/ C), PL 6.1.1
Troubleshooting Procedure
Step Actions and Questions
1. Replace the Imaging Unit (Y/ M/ C) (REP 6.0 Imaging Unit (Y/ M/ C/ K) on page 4-121).
