Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-428
Feed Roller Clutch (Tray 2/ 3/ 4)
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• MCU PWB, PL 12.1.15
• Option Harness Assembly, PL 12.3.5
• Feed Roller Clutch, PL 15.2.13
•Option Feeder 1 Relay Harness Assembly, PL 15.2.30
•Option Rear Feeder Harness Assembly, PL 15.2.32
• Feeder PWB, PL 15.2.33
• 550-Sheet Feeder on page 7-64
Troubleshooting Procedure
Step Actions and Questions Yes No
1. Check the Feed Roller Clutch operation.
Perform DC330 Component Control on
page 2-26 to check the operation of the Turn
Roller Clutch:
• Tray 2 [071-026]
• Tray 3 [071-027]
• Tray 4 [071-028]
Is the Feed Roller Clutch operating properly?
Replace the MCU PWB
(REP 12.4 MCU PWB
on page 4-206).
Go to step 2.
2. Check the connection between the Feed Roller
Clutch and Feeder PWB.
Are the connectors P/J220 and P/J421 connected
securely?
Go to step 3. Connect the
connectors P/J220 and
P/J421.
3. Check the conductivity between the Feed Roller
Clutch and Feeder PWB.
Is the connection between P/J220 <=> P/J421
conducting properly?
Go to step 4. Replace the Option
Rear Feeder Harness
Assembly.
4. Check the resistance of the Turn Roller Clutch
Turn Off the power, remove the Turn Roller Clutch
(REP 15.18 Turn Roller Clutch on page 4-280),
and check the wire resistance between the two
terminals.
Is the resistance approximately 144 Ohms (at
68° F)?
Go to step 5. Replace the Turn Roller
Clutch (REP 15.18 Turn
Roller Clutch on
page 4-280).
