Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-264
Bypass Tray Miss Feed Jam
After a paper was fed from the Bypass Tray, it did not reach the Registration Sensor.
Applicable Fault Code
• 075-100: Bypass Tray Miss Feed Jam
Initial Actions
• Check the condition of the paper in tray.
• Check that the media is supported from tray.
• Check that the Paper Guides are set correctly.
• Check appropriate tray jam clearance door.
• If the problem persists, perform the following procedure.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• Retard Roller (Separator Retard Holder Assembly), PL 3.1.8
• Bypass Tray Feed Solenoid, PL 4.3.10
• Bypass Tray Feed Roller Assembly, PL 4.4.14
• Registration Sensor, PL 5.1.3
• Bypass Tray Turn Roller, PL 5.1.8
• Turn Clutch Assembly, PL 5.1.9
• Paper Handling Motor (P/H Drive Assembly), PL 11.1.19
• MCU PWB, PL 12.1.15
• Power on page 7-38
Troubleshooting Procedure
Step Actions and Questions Yes No
1. Check the paper transport path.
Is there any debris on the paper transport path?
Remove the debris
from the paper
transport path.
Go to step 2.
2. Check the installation of the Feed Roller (REP
4.13 Bypass Tray Feed Roller Assembly on
page 4-112).
Is the Feed Roller installed properly?
Go to step 3. Reinstall the Feed
Roller.
3. Check the Feed Roller.
Is the Feed Roller deformed or worn out?
Replace the Feed Roller
(REP 4.13 Bypass Tray
Feed Roller Assembly
on page 4-112).
Go to step 4.
