Xerox Phaser 7100 Service Manual

Plug/Jack and Wiring Diagrams
Xerox Internal Use Only Phaser 7100 Service Manual 7-53
Electrical
Electrical Signal Lines
Signal Line Name Description
Data (EEPROM PWB) The Data Read/ Write Control signal to the EEPROM PWB
Clock (EEPROM PWB)
Temp The temperature data in the printer that is measured by the Temp/
Humidity (Environmental) Sensor (analog value)
Humi The humidity data in the printer that is measured by the Temp/
Humidity (Environmental) Sensor (analog value)
Deve Fan On The On/ Off Control Signal of the Developer Fan (Developer Fan)
Deve Fan Alarm The Alarm signal from the Developer Fan
Waste Auger (Trickle) Motor On The On/ Off Control signal of the Waste Auger (Trickle) Motor
MCU PWB
P/J465B
5
6
Deve Fan On
Deve Fan Alarm
1
2
J4652B
4
3
7
RTN
32
41
P/J465B
P/J492
8
Waste Auger (Trickle) Motor On
1
J4653B
2
9
1
2
I/L +24VDC
21
M
Waste Auger
(Trickle) Motor
Deve Fan
EEPROM PWB
P/J460
1
2
3
4
P/J144
4
3
2
1
P/J465B
1
2
3
4
P/J4651B
4
3
2
1
Temp/Humidity
(Environmental)
Sensor
10
11
Data
Clock
+3.3VDC
SG
Temp
SG
Humi
+5VDC
Waste Auger
(Trickle) Assembly
+3.3VDC
+5VDC
N.C.
N.C.
N.C.
N.C.
N.C.
I/L +24VDC
s7100-308
