Xerox Phaser 7100 Service Manual

Plug/Jack and Wiring Diagrams
Phaser 7100 Service Manual Xerox Internal Use Only7-62
Option Duplex Wiring Diagram
Duplex
E Duplex PWB
MCU PWB
P/J467
1
2
3
P/J429
1
2
3
4
5
6
I/L +24VDC
+3.3VDC
P/J430
1
2
3
P/J431
1
2
I/L +24VDC
I/L +24VDC
I/L +24VDC
A
B
/A
/B
M
Duplex Motor
Duplex Jam Sensor
P/J125
3
2
1
+3.3VDC
SG
DUP PAPER SENSED SIGNAL
Duplex Clutch
I/L +24VDC
DUP CLUTCH ON
4
5
6
7
8
9
10
J4671
10
P4671
1
29
38
47
56
65
74
83
92
101
J4672
1
P4672
10
92
83
74
65
56
47
38
29
110
P/J428
10
9
8
7
6
5
4
3
2
1
RTN
RTN
RTN
I/L +24VDC
I/L +24VDC
SG
+3.3VDC
DUP HOTLINE
DUP TXD
DUP RXD
I/L +24VDC
+3.3VDC
s7100-313

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
