Plug/Jack and Wiring Diagrams
Xerox Internal Use Only Phaser 7100 Service Manual 7-61
Development Signal Lines
Signal Line Name Description
Clock (Cartridge Assy (Y)) The Data Read/ Write Control signal to the CRUM in the Cartridge
Assembly (Y)
Data (Cartridge Assy (Y))
Clock (Cartridge Assy (M)) The Data Read/ Write Control signal to the CRUM in the Cartridge
Assembly (M)
Data (Cartridge Assy (M))
Clock (Cartridge Assy (C)) The Data Read/ Write Control signal to the CRUM in the Cartridge
Assembly (C)
Data (Cartridge Assy (C))
Clock (Cartridge Assy (K)) The Data Read/ Write Control signal to the CRUM in the Cartridge
Assembly (K)
Data (Cartridge Assy (K))
Disp Motor Y On The On/ Off Control signal of the Toner Dispense Motor (Y)
Disp Motor M On The On/ Off Control signal of the Toner Dispense Motor (M)
Disp Motor C On The On/ Off Control signal of the Toner Dispense Motor (C)
Disp Motor K On The On/ Off Control signal of the Toner Dispense Motor (K)
