Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-452
Feeder Composition
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• MCU PWB, PL 12.1.15
• Duplex Unit, PL 14.1.1
• 550-Sheet Feeder Assembly, PL 15.1.2
Troubleshooting Procedure
Step Actions and Questions Yes No
1. Check the connection of the 550-Sheet Feeder
Assembly.
Is 4 or more Sheet Feeder Assembly connected?
Remove the extra 550-
Sheet Feeder Assembly
until only 3 or fewer
are left.
Go to step 2.
2. Check the connection of 550-Sheet Feeder
Assembly.
Is there an Option Feeder for other than this
printer installed?
Connect the 550-Sheet
Feeder Assembly to
the printer.
Go to step 3.
3. Check the Duplex Unit.
Is there an Option Duplex Unit for other than this
printer installed?
Connect the Duplex
Unit to the printer.
Replace the MCU PWB
(REP 12.4 MCU PWB
on page 4-206).

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
