Print Data Flow
Data Flow
The print data (electric signals) from the printer Controller processes to become a print image is shown
in the following diagram.
Host (Electric Signal)
Printer Controller (Electric Signal)
ROS Assembly (Laser Beam)
Electrostatic latent image on the Drum
Toner image on the Drum (visible image)
Toner image on the Intermediate Transfer
Toner image on the paper
Print image on the paper
s7100-368

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
