Xerox Phaser 7100

General and Operation Overview
Xerox Internal Use Only Phaser 7100 Service Manual 1-43
Waste Cartridge - Collects the waste toner that is generated during the cleaning of the Intermediate
Transfer Belt.
Figure 2 - Waste Toner Collection Path to the Waste Cartridge
s7100-186
Waste Toner Motor
Paddle (Waste Box)
Waste Cartrid
g
eWaste Box Full Sensor
Paddle (Cleaner)
Cleaning Blade
