Xerox Phaser 7100 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-121
Out of ART EX Memory
An insufficient memory was detected while using the ART EX.
Applicable Fault Code
• 016-701: Insufficient PLW Decomposer Memory
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Out of Page Buffer
Not a single page could be compressed. Insufficient Print Page Buffer was detected.
Applicable Fault Code
• 016-702: Unable to Compress Page due to Insufficient Print Page Buffer
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Troubleshooting Procedure
Step Actions and Questions
1. Increase the allocated memory of the ART EX. (In some cases, actual memory must be increased.)
2. Change the print mode. (Example: High Quality mode > Normal mode)
3. Reduce the resolution.
4. Set Page Print mode to Enabled.
5. Perform Image Compression in the Graphics tab of the Print Driver.
Troubleshooting Procedure
Step Actions and Questions
1. Set Print Mode to High Speed and reduce the print resolution before retrying the operation.
2. Increase the memory to increase the page buffer.
3. Retry the operation in Print Page Mode. (PLW Decomposer (=ART-EX) only)
For Print Page Mode, refer to the Print Driver online help.

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
