Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-187
Shortage of Memory Capacity, or No Hard Disk
The printer, when satisfies conditions 1 and 2, is to perform a job that has any of these -
AnalogWaterMark/ HighbridWaterMark/ UUID added to it.
Condition 1: Any of the SW options “Paper Security Kit”, “Annotation Kit”, or “Sa kura Paper Kit” is
enabled. Note that this includes cases where two or more options are enabled.
Condition 2: The HDD is not installed on the Controller PWB, or the system memory capacity is
insufficient to operate the SW options enabled in Condition 1.
Applicable Fault Code
• 024-700: A job that could not be printed due to unfulfilled conditions such as [Insufficient System
Memory] or [HDD Not Installed] was received
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• HDD Productivity Kit, PL 12.4.20
Troubleshooting Procedure
Step Actions and Questions
1. Install the HDD to the I/P PWB.
2. Install the memory capacity that is needed by the SW Option enabled in Condition 1 to the I/P PWB
(the required capacity depends on the printer model).
3. After completing steps 1 and 2, turn On the power and check that neither 016-210 nor 016-211 is
displayed on the Control Panel.
If it is displayed, refer to the corrective actions for 016-210 or 016-211.

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
