Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-310
(Y/ M/ C/ K) Toner Cartridge Error: Detached
The (Y/ M/ C/ K) Toner Cartridge CRUM is loose.
Applicable Fault Codes
• 093-913: Toner CRUM Not Position Y
• 093-914: Toner CRUM Not Position M
• 093-915: Toner CRUM Not Position C
• 093-916: Toner CRUM Not Position K
Initial Actions
• Check the Toner Cartridge life. Access CWIS > Status > Consumables.
• If the problem persists, perform the following procedure.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• Toner Cartridge Assembly (K), PL 8.1.4
Troubleshooting Procedure
Step Actions and Questions
1. Reinstall the Toner Cartridge (Y/ M/ C/ K) (REP 8.0 Toner Cartridge Assembly (Y/ M/ C/ K) on
page 4-136).
