Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-318
2nd BTR Error: Life End
When the 2nd BTR Unit (Transfer Roller) HFSI Counter reached the 2nd BTR Unit End Warning (NVM).
Applicable Fault Code
• 094-422: 2nd BTR Unit End Warning (Quality Life End)
Initial Actions
• Check the Transfer Roller life. Access CWIS > Status > Consumables.
• If the problem persists, perform the following procedure.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• Transfer Roller (2nd BTR Unit), PL 4.3.18
Troubleshooting Procedure
Step Actions and Questions
1. Replace the Transfer Roller (REP 4.10 Transfer Roller (2nd BTR Unit) on page 4-108).
2. Perform DC135 HFSI on page 2-19 and reset the following Life Counters for the 2nd BTR.
• 950-872 - 2nd BTR PV

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
