Plug/Jack and Wiring Diagrams
Phaser 7100 Service Manual Xerox Internal Use Only7-52
P-Size 0
The On/ Off Detection signal of SW 0 for the Paper Size Switch (
*
1
)
P-Size 1 The On/ Off Detection signal of SW 1 for the Paper Size Switch
P-Size 2 The On/ Off Detection signal of SW 2 for the Paper Size Switch
P-Size 3 The On/ Off Detection signal of SW 3 for the Paper Size Switch
*
1
The Paper Size Switch is numbered from top to down as SW 0, SW 1, SW 2, and SW 3.
Paper Transport Signal Lines (Continued)
Signal Line Name Description
To Next Page
