Xerox Phaser 7100 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-181
024-347 ~ 024-351/ 024-354/ 024-356/ 024-359/ 024-360
Communication error has occurred due to one of the following problems:
• Communication failure has occurred because no ACK was received despite having re-sent twice. (A
framing error was detected in the hardware at the IOT side.)
• Communication failure has occurred because no ACK was received despite having re-sent twice.
(An overrun error was detected in the hardware at the IOT side.)
• Communication failure has occurred because no ACK was received despite having re-sent twice.
(Receive abort was detected after header authentication at the IOT side.
• This occurs when the NAK that notifies the occurrence of communication failure was received.
(The Sequence No. of the received Message Packet is incorrect.)
• This occurs when the NAK that notifies the occurrence of communication failure was received.
(The Packet No. of the received Message Packet is incorrect.)
• This occurs when the NAK that notifies the occurrence of communication failure was received. (A
parity error was detected in the hardware of the UART.)
• This occurs when the NAK that notifies the occurrence of communication failure was received. (An
overrun error was detected by hardware of the UART.)
• An abnormal parameter was set in the argument of the receiving function, which causes an error.
• IOT Driver initialization failure.
Applicable Fault Codes
• 024-347: (IOT) - MCU Send Framing Error Detected by Controller
• 024-348: (IOT) - MCU Send Error Detected by Controller (Overrun error)
• 024-349: (IOT) - MCU Send Error Detected by Controller (Receive abort error)
• 024-350: (IOT) - MCU Receive Error Detected by Controller (Sequence No. error)
• 024-351: (IOT) - MCU Receive Error Detected by Controller (Packet No. error)
• 024-354: (IOT) - MCU Receive Error Detected by Controller (Parity error)
• 024-356: (IOT) - MCU Receive Overrun Error Detected by Controller
• 024-359: MCU transmission receiving error detected by Controller (Invalid parameter was used)
• 024-360: MCU transmission receiving error detected by Controller (Invalid parameter was used)
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• Image Processor PWB, PL 12.4.1
