Plug/Jack and Wiring Diagrams
Xerox Internal Use Only Phaser 7100 Service Manual 7-7
4521 6 G-110 Connection between the Main Harness Assembly (PL 12.3.1) and the (K)
Harness Assembly (PL 11.1.23).
9 F-111
4522 6 F-110 Connection between the Main Harness Assembly (PL 12.3.1) and the PR
(K) Harness Assembly (PL11.1.23).
9E-111
4523 2 H-103 Connection between the (Y/ M/ C) CRUM X Harness Assembly (PL 6.1.15)
and the (Y) Erase PWB (PL 6.1.9).
4524 2 H-104 Connection between the (Y/ M/ C) CRUM X Harness Assembly (PL 6.1.15)
and the (M) Erase PWB (PL 6.1.9).
4525 2 I-104 Connection between the (Y/ M/ C) CRUM X Harness Assembly (PL 6.1.15)
and the (C) Erase PWB (PL 6.1.9).
4526 2 I-105 Connection between the (K) CRUM X Harness Assembly (PL 6.1.14) and
the (K) Erase PWB (PL 6.1.9).
4541 2 B-103 Connection between the Toner CRUM Harness Assembly (PL 8.1.18) and
the (Y) Toner CRUM Connector Assembly (PL 8.1.13).
4542 2 C-103 Connection between the Toner CRUM Harness Assembly (PL 8.1.18) and
the (M) Toner CRUM Connector Assembly (PL 8.1.13).
4543 2 C-104 Connection between the Toner CRUM Harness Assembly (PL 8.1.18) and
the (C) Toner CRUM Connector Assembly (PL 8.1.13).
4544 2 D-104 Connection between the Toner CRUM Harness Assembly (PL 8.1.18) and
the (K) Toner CRUM Connector Assembly (PL 8.1.13).
4551 6 G-110 Connection between the Main Harness Assembly (PL 12.3.1) and the (K)
CRUM X Harness Assembly (PL 6.1.14).
9 F-112
4552 2 H-103 Connection between the (Y/ M/ C) CRUM X Harness Assembly (PL 6.1.15)
and the (Y) Imaging Unit CRUM Connector Assembly (PL 6.1.6).
4553 2 H-104 Connection between the (Y/ M/ C) CRUM X Harness Assembly (PL 6.1.15)
and the (M) Imaging Unit CRUM Connector Assembly (PL 6.1.6).
4554 2 I-104 Connection between the (Y/ M/ C) CRUM X Harness Assembly (PL 6.1.15)
and the (C) Imaging Unit CRUM Connector Assembly (PL 6.1.6).
4561 2 D-112 Connection between the Main CTD Harness Assembly (PL 12.3.8) and the
Temperature Sensor (CTD Sensor Assembly) (PL 9.1.10).
4571 2 C-112 Connection within the Main CTD Harness Assembly (PL 12.3.8).
4572 2 C-112 Connection between the Main CTD Harness Assembly (PL 12.3.8) and the
CTD Harness (CTD Sensor Assembly) (PL 9.1.10).
4573 2 D-112 Connection between the Main CTD Harness Assembly (PL 12.3.8) and the
Left CTD Sensor (CTD Sensor Assembly) (PL 9.1.10).
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks
