Plug/Jack and Wiring Diagrams
Phaser 7100 Service Manual Xerox Internal Use Only7-8
4574 2 G-111 Connection between the CTD Harness (CTD Sensor Assembly) (PL 9.1.10)
and the Right CTD Sensor (CTD Sensor Assembly) (PL 9.1.10).
4611 8 E-107 Connection between the Option Harness Assembly (PL 12.3.5) and the
Option Feed 1 Relay Harness Assembly (PL 15.2.30) (Option 550 Feeder).
4621 8 C-104 Connection between the Dispense Harness Assembly (PL 8.1.19) and the
(Y) Dispense Motor Assembly (PL 8.1.15).
4622 8 D-104 Connection between the Dispense Harness Assembly (PL 8.1.19) and the
(M) Dispense Motor Assembly (PL 8.1.15).
4623 8 E-104 Connection between the Dispense Harness Assembly (PL 8.1.19) and the
(C) Dispense Motor Assembly (PL 8.1.15).
4624 8 F-105 Connection between the Dispense Harness Assembly (PL 8.1.19) and the
(K) Dispense Motor Assembly (PL 8.1.15).
4651A 1 H-111 Connection between the Main Harness Assembly (PL 12.3.1) and the
Feeder Harness Assembly (PL 2.2.3).
9 C-111
4651B 6 E-110 Connection between the Main Harness Assembly (PL 12.3.1) and the
Temp/ Humidity (Environmental) Sensor (PL 12.2.18).
9 D-111
4652A 1 H-111 Connection between the Feeder Harness Assembly (PL 2.2.3) and the No
Paper Sensor (PL 2.2.2).
9 C-110
4652A 1 E-111 Connection between the Main Harness Assembly (PL 12.3.1) and the
Feed Roller Clutch (Paper Handling Clutch Assembly) (PL 2.2.8).
4652B 6 G-109 Connection between the Main Harness Assembly (PL 12.3.1) and the
Developer Fan (Process Fan) (PL 12.2.16).
9 F-111
4653A 6 I-110 Connection between the Main Harness Assembly (PL 12.3.1) and the
Paper Size Switch (Size Switch Holder Assembly) (PL 2.1.6).
9 I-112
4653B 2 B-106 Connection between the Main Harness Assembly (PL 12.3.1) and the
Trickle Motor (Trickle Guide Assembly) (PL 8.1.10).
9 D-106
4661 10 F-106 Connection between the Main Harness Assembly (PL 12.3.1) and the
Front Harness Assembly (PL 4.2.11).
11 E-103
4662 2 E-103 Connection between the Front Harness Assembly (PL 4.2.11) and the BTR
Retract Motor (IBT Retract Cam Assembly) (PL 9.1.8).
4663 2 D-103 Connection between the Front Harness Assembly (PL 4.2.11) and the BTR
Retract Sensor (IBT Retract Cam Assembly) (PL 9.1.8).
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks
