Xerox Phaser 7100 Service Manual

Plug/Jack and Wiring Diagrams
Xerox Internal Use Only Phaser 7100 Service Manual 7-9
4671 6 C-111 Connection between the Main Harness Assembly (PL 12.3.1) and the
Duplex Harness Assembly (PL 4.2.18) (Option Duplex).
9 B-111
13 C-110
4672 1 I-102 Connection between the Duplex Harness Assembly (PL 4.2.18) and the
Duplex Relay Harness Assembly (PL 14.3.19).
4681 4 E-109 Connection between the Main Harness Assembly (PL 12.3.1) and the Top
Harness Assembly (PL 12.2.24).
10 F-106
11 E-102
4682 3 I-105 Connection between the Top Harness Assembly (PL 12.2.24) and the
Front Cover Switch (PL 12.2.7).
5E-110
4683 3 D-106 Connection between the Top Harness Assembly (PL 12.2.24) and the
HVPS2 Fan (Process Fan) (PL 12.1.3).
5E-105
4684 3 E-104 Connection between the IBT Cleaner Motor Assembly (PL 9.1.6) and the
LVPS PWB (PL 12.2.1).
4E-107
4685 3 D-105 Connection between the IBT Unit (PL 9.1.99) and the LVPS PWB (PL
12.2.1).
4 F-107
4686 3 D-106 Connection between the Waste Sensor Harness (Waste Cartridge Guide
Assembly) (PL 9.1.4) and the Waste Cartridge Full Sensor (PL 9.1.5).
4691 10 G-109 Connection between the Main Harness Assembly (PL 12.3.1) and the
Laser Unit (ROS Assembly) (PL 7.1.1).
11 E-110
4711 8 G-106 Connection between the Paper Handling Motor Harness Assembly (PL
12.3.9) and the Paper Handling Motor (Paper Handling Drive Assembly)
(PL 11.1.19).
4721 6 J-109 Connection between the Main Harness Assembly (PL 12.3.1) and the (Y/
M/ C) PR Harness Assembly (PL 11.1.22).
9 H-111
4722 6 H-108 Connection between the PR (Y/ M/ C) Harness Assembly (PL 11.1.22) and
the (Y/ M/ C) Drum Motor (Drive Assembly) (PL 11.1.2).
4723 6 H-110 Connection between the Main Harness Assembly (PL 12.3.1) and the (Y/
M/ C) CRUM X Harness Assembly (PL 6.1.15).
9 G-112
4724 6 F-109 Connection between the PR (K) Harness Assembly (PL 11.1.23) and the
(K) Drum Motor (K Drive Assembly) (PL 11.1.12).
4731 1 F-111 Connection between the Registration Harness (Registration Chute
Assembly) (PL 5.1.1) and the Registration Sensor (PL 5.1.3).
Print Engine Plug/Jack Designators (Continued)
