Xerox Phaser 7100 Service Manual

Parts List
Xerox Internal Use Only Phaser 7100 Service Manual 5-61
Parts List 15.1 550-Sheet Feeder (1 of 2)
Item Description Part Number
1. Tray Assembly 550 604K76922
2. 550-Sheet Feeder Assembly (with 3-13, 15, 20, 21, PL 15.2) (REP
15.1 550-Sheet Feeder Assembly)
See Supplies and Accessories
3. Right Feeder Cover 550 (REP 15.2 550 Right Feeder Cover)
4. E Optional Foot
5. Size Switch Holder Assembly (REP 15.3 Size Switch Holder
Assembly on page 4-263)
019K07952
6. Right Tray Guide 550 (with 5) (REP 15.4 550 Right Tray Guide on
page 4-264)
7. Protect Cover Assembly (REP 15.5 Protect Cover Assembly on
page 4-265)
8. Nudger Spring
9. Left Tray Guide 550 (with 10, 20) (REP 15.6 550 Left Tray Guide on
page 4-266)
10. Tray Feeder Stopper (REP 15.7 Tray Feeder Stopper on page 4-267) 003E74910
11. Left Feeder Cover 550 (REP 15.8 550 Left Feeder Cover on
page 4-268)
12. Earth Spring
13. Tray Cover (REP 15.9 Tray Cover on page 4-269) 848E42770
14. Joint Feeder Screw M4 826E16531
15. Turn Chute Assembly (with PL 15.2.1 - PL 15.2.5) (REP 15.10 Turn
Chute Assembly on page 4-270)
054K42631
16. -----
17. -----
18. -----
19. -----
20. Left Tray Guide 550
21. Rubber Foot
