Xerox Phaser 7100

Parts List
Xerox Internal Use Only Phaser 7100 Service Manual 5-67
28. Exit Housing Assembly (REP 15.27 Exit Housing Assembly on
page 4-292)
29. Gear Sector Assembly
30. Exit Cover
31. End Guide Assembly 550 (REP 15.28 End Guide Assembly on
page 4-293)
32. A4 Exit Lock (REP 15.29 Exit Lock on page 4-295)
33. Exit Lock Link
34. Bottom Plate Link
35. Lock Rack Pin
36. Link Lock Spring
37. PB Right Gear
38. PB Roller
39. Bottom Lock Pinion Gear
40. Bottom Lock Gear 40
41. Bottom Lock Lever Assembly 550
42. Bottom Lock Lever Gear
43. Bottom Lock Spring
44. Bottom Lock Rack 550
45. Left Gear Lock Plate 550
46. Bottom Up Cover Assembly 550
47. Base Housing 550
Parts List 15.3 Tray 550 (Continued)
Item Description Part Number
