Plug/Jack and Wiring Diagrams
Xerox Internal Use Only Phaser 7100 Service Manual 7-55
Transfer Signal Lines
Signal Line Name Description
CTD L VOut The toner density measured value by the Left CTD Sensor
LED On (CTD Sensor L) The LED On signal of the Left CTD Sensor
CTD L VMonitor The power monitor voltage value of the Left CTD Sensor
CTD R VOut The toner density measured value by the Right CTD Sensor
LED ON (CTD Sensor R) The LED On signal of the Right CTD Sensor
CTD R VMonitor The power monitor voltage value of the Right CTD Sensor
Temp Signal The temperature data in the printer that is measured by the
Temperature Sensor (analog value)
Belt RET MOT On The On/ Off Control signal of the Belt Retract Motor
Belt Sensor Signal The 1st BTR Belt Contact/ Retract Detection signal by the Belt Retract
Sensor
Front Cover Open The Front Cover Open/ Close detection by the Front Cover Switch
(Cover open: H)
HVPS2 Fan On The On/ Off Control signal of the HVPS2 Fan
HVPS2 Fan ALRM The Alarm signal from the HVPS2 Fan
Waste Toner Motor On The On/ Off Control signal of the Waste Toner Motor
Waste Cartridge Full Signal The signal for detecting the Waste Toner Full in the Waste Cartridge by
the Waste Cartridge (Toner) Full Sensor
To Next Page
