Xerox Phaser 7100 Service Manual

Plug/Jack and Wiring Diagrams
Xerox Internal Use Only Phaser 7100 Service Manual 7-65
Option 550-Sheet Feeder Signal Lines
Signal Line Name Description
Feed Tray Sens The Clock signal that is used by the CPU on the Feeder PWB to
determine the level at which it is installed to.
(Sent from the MCU PWB)
Feed RXD The Communication signal between the MCU PWB and the Feeder
PWB
Feed TXD
Turn Roll Clutch On The On/ Off Control signal of the Turn Roller Clutch
Paper Jam Sensed Signal The signal for detecting paper at the Paper Feed Position of the Option
Tray by the Paper Jam Sensor
(Paper detected: L)
OP Feed Motor On The On/ Off Control signal of the Feeder Motor
OP Feed Motor Alarm The Alarm signal from the Feeder Motor
OP Feed Motor Clock The Clock signal of the Feeder Motor
OP Feed Motor Gain The Control signal of the Feeder Motor
Feed Roll Clutch On The On/ Off Control Signal of the Feed Roller Clutch
Paper Sensed Signal The signal for detecting paper in the Option Tray by the Feeder No
Paper Sensor
P-Size 0
The On/ Off Detection signal of SW 0 for the Paper Size Switch (
* 1 )
P-Size 1 The On/ Off Detection signal of SW 1 for the Paper Size Switch
P-Size 2 The On/ Off Detection signal of SW 2 for the Paper Size Switch
P-Size 3 The On/ Off Detection signal of SW 3 for the Paper Size Switch
* 1 The Paper Size Switch is numbered from top to down as SW 0, SW 1, SW 2, and SW 3.

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
