Xerox Phaser 7100

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-237
5. Check the conductivity between the Relay
Connector and MCU PWB.
Is the connection between P/J4681 <=> P/J468
conducting properly?
Replace the HVPS2
Fan (REP 12.2 HVPS2
Fan on page 4-203).
Replace the Top
Harness Assembly.
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
