Xerox Phaser 7100

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-312
2. Check the CRUM PWB part of the Toner
Cartridge (Y/ M/ C/ K).
Is the connection terminal of the CRUM PWB
part in the Toner Cartridge (Y/ M/ C/ K)
damaged?
Replace the Toner
Cartridge (Y/ M/ C/ K)
(REP 8.0 Toner
Cartridge Assembly (Y/
M/ C/ K) on
page 4-136).
Go to step 3.
3. Check the Toner CRUM Connector Assembly.
Is the connection terminal of the Toner CRUM
Connector Assembly damaged?
Replace the Toner
CRUM Connector
Assembly
(REP 8.5 Toner CRUM
Connector Assembly
on page 4-151).
Go to step 4.
4. Check the connection between the Toner CRUM
Connector Assembly and MCU PWB.
Are the connectors connected securely?
• (Y) Toner CRUM: P/J4541 <=> P/J454
• (M) Toner CRUM: P/J4542 <=> P/J454
• (C) Toner CRUM: P/J4543 <=> P/J454
• (K) Toner CRUM: P/J4544 <=> P/J454
Go to step 5. Connect the
connectors:
•(Y) Toner CRUM:
P/J4541 and
P/J454
•(M) Toner CRUM:
P/J4542 <=>
P/J454
• (C) Toner CRUM:
P/J4543 <=>
P/J454
•(K) Toner CRUM:
P/J4544 <=>
P/J454
5. Check the conductivity between the Toner CRUM
Connector Assembly and MCU PWB.
Is the connection between the connectors
conducting properly?
• (Y) Toner CRUM: P/J4541 <=> P/J454
• (M) Toner CRUM: P/J4542 <=> P/J454
• (C) Toner CRUM: P/J4543 <=> P/J454
• (K) Toner CRUM: P/J4544 <=> P/J454
Replace the MCU PWB
(REP 12.4 MCU PWB
on page 4-206).
Replace the Toner
CRUM Harness
Assembly.
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
