Xerox Phaser 7100

General and Operation Overview
Phaser 7100 Service Manual Xerox Internal Use Only1-34
Ready/ Sleep Mode
Engine State
• Ready Mode: ROS Motor Off, Fuser Ready
• Lower Power Mode: ROS Motor Off, Fuser Ready
• Sleep Mode: ROS Motor Off, Fuser Off
•No Setup cycle
Continuous Print Speed (ppm)
Continuous print speed is defined as the average print speed for the 2nd sheet onwards.
Note: The listed speeds do not take into account “various setup/cleaning/sagging/process
control.”
Mode Color B/ W
Simplex Duplex Simplex Duplex
Ready Mode 9.9 sec or less 16.0 sec or less 8.3 sec or less 14.0 sec or less
100V Sleep Mode 21.9 sec or less *228.0 sec or less *220.3 sec or less *2 26.0 sec or less *2
100V Sleep Mode 25.9 sec or less *232.0 sec or less *224.3 sec or less *2 30.0 sec or less *2
230V Sleep Mode 27.9 sec or less *234.0 sec or less *226.3 sec or less *2 32.0 sec or less *2
* 1: 1 batch for Dup
* 2: Changes depending on input voltage.
Print Mode Print
Media
Mode
Bypass Tray 250-Sheet Tray 550-Sheet Tray
Tray 1 Tray 2/ 3/ 4
Speed Sim Dup Sim Dup Sim Dup
Normal ModeColorFull302230213022
Half 15 11 15 10.5 15 11
B/WFull302230213022
Half 15 11 15 10.5 15 11
* For Duplex mode calculations, front and back sides are considered separate pages.
