Xerox Phaser 7100

Image Quality
Phaser 7100 Service Manual Xerox Internal Use Only3-24
10. Check the Transfer Roller (2nd BTR).
Is the Transfer Roller normal, without any
contamination, damage, or wear and tear?
Go to step 11. Replace the Transfer
Roller (REP 4.10
Transfer Roller (2nd
BTR Unit) on
page 4-108).
Reset the Transfer
Roller counter
(Resetting the Transfer
Roller (2nd BTR)
Counter on
page 6-12).
11. Replace the IBT Unit (REP 9.10 IBT Unit on
page 4-177).
Does the error persist?
Go to step 12. Troubleshooting
complete.
12. Check the HVPS2 PWB connectors.
Are the connectors seated securely?
Replace the HVPS2
PWB (REP 12.1 HVPS2
PWB on page 4-202).
Reconnect the wiring
harness connectors.
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
