Xerox Phaser 7100 Service Manual

Image Quality
Phaser 7100 Service Manual Xerox Internal Use Only3-26
4. Check the IBT Unit (Transfer Belt).
Is the Transfer Belt normal, without
contamination, damage, or wear and tear?
Go to step 5. Replace the IBT Unit
(REP 9.10 IBT Unit on
page 4-177).
5. Replace the IBT Unit (REP 9.10 IBT Unit on
page 4-177).
Does the error persist?
Go to step 6. Troubleshooting
complete.
6. Check the Developer Housing Assembly.
Is the Developer Housing Assembly (Y/ M/ C/ K)
normal, without any contamination, damage, or
wear and tear?
Replace the MCU PWB
(REP 12.4 MCU PWB
on page 4-206).
Replace the Developer
Housing Assembly
(REP 8.1 Developer
Housing Assembly (Y/
M/ C/ K) on
page 4-137).
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
