Parts List
Phaser 7100 Service Manual Xerox Internal Use Only5-12
25. Front Cover Strap
26. Front Cover
27. Front Latch Assembly (with 28-31, 34) (REP 1.14 Front Latch
Assembly and Latch Spring on page 4-33)
28. Flange Screw
29. Right Front Latch
30. Front Latch Plate
31. Left Front Latch
32. Latch Spring (REP 1.14 Front Latch Assembly and Latch Spring on
page 4-33)
33. Harness Guide
34. ER Latch Stopper
35. Control Panel (UI) Harness Assembly
36. Waste Arm Support
37. Waste Cover Hinge Spring
38. Front Cover Assembly (with 18-35) (REP 1.15 Front Cover Assembly
on page 4-35)
604K76943
Parts List 1.1 Cover (Continued)
Item Description Part Number
