Xerox Phaser 7100 Service Manual

Parts List
Phaser 7100 Service Manual Xerox Internal Use Only5-14
Parts List 2.1 250-Sheet Feeder (1 of 2)
Item Description Part Number
1. Feeder Assembly (with PL 2.2) (REP 2.1 Feeder Assembly on
page 4-37)
059K65242
2. Right Turn Gear Assembly (REP 2.2 Right Turn Gear Assembly on
page 4-39)
007K16930
3. Right Feeder Cover 250 (REP 2.3 Right Feeder Cover on page 4-40) 848E42760
4. Right Turn Bracket Assembly (REP 2.4 Right Turn Bracket Assembly
on page 4-41)
068K69391
5. Right Tray Guide Assembly 250 (with 6) (REP 2.5 Right Tray Guide
Assembly on page 4-42)
6. Size Switch Holder Assembly (REP 2.6 Size Switch Holder Assembly
on page 4-43)
019K07952
7. Nudger Spring
8. Protect Cover Assembly (REP 2.7 Protect Cover Assembly on
page 4-44)
9. Left Tray Guide Assembly 250 (with 10) (REP 2.8 Left Tray Guide
Assembly on page 4-47)
10. Tray Stopper (REP 2.9 Tray Stopper on page 4-48) 803E12630
11. Tray Assembly 250 (with PL 2.3) 050K69895
12. Foot
13. Left Feeder Cover 250 (REP 2.10 Left Feeder Cover on page 4-49) 848E42190
14. Tray Cover (REP 2.11 Tray Cover on page 4-50) 848E42770
15. Rubber Foot
16. Front Harness Cover

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
