Xerox Phaser 7100

Parts List
Phaser 7100 Service Manual Xerox Internal Use Only5-16
Parts List 2.2 250-Sheet Feeder (2 of 2)
Item Description Part Number
1. Turn Roller Assembly (IOT) (REP 2.12 Turn Roller Assembly on
page 4-51)
2. No Paper Sensor 250 (REP 2.13 No Paper Sensor on page 4-52) 130E87280
3. Feeder Harness Assembly
4. Clamp
5. Retard Chute Assembly 250
6. Bearing
7. Nudger Bearing
8. Feed Roller Clutch (Paper Handling Clutch Assembly 250) (REP
2.14 Feed Roller Clutch on page 4-53)
121K45670
9. Top Right Retard Holder
10. Nudger Support Assembly
11. Feed Roller (REP 2.15 Feed Roller/ Retard Roller Assembly on
page 4-54)
Included with Tray 1 Feed Roller
Kit (see PL 2.2.99)
12. Oneway Feed Clutch
13. Oneway Nudger Clutch
14. Feed Shaft
99. Tray 1 Feed Roller Kit (with 11, PL 2.3.44) (REP 2.15 Feed Roller/
Retard Roller Assembly on page 4-54)
604K78861
